THIS GUIDE WILL SHOW YOU HOW MUCH SPACE IS REQUIRED ON YOUR TOOL BOX TO MOUNT OUR TOOLBOX MOUNT BIKE RACK. INSTALLATION IS VERY SIMPLE. SIMPLY DRILL 4 HOLES AND BOLT ON.

USE THIS FITTING GUIDE TO SEE IF OUR DRAWBAR MOUNT BIKE RACK WILL WORK WITH YOUR SET UP.

NOTE: VERTICAL SUPPORT BARS CAN BE CUT SHORTER TO KEEP THE BIKE RACK LOW ON YOUR DRAWBAR.

USE THIS FITTING GUIDE TO SEE IF OUR DRAWBAR MOUNT BIKE RACK WILL WORK WITH YOUR SET UP.

NOTE: VERTICAL SUPPORT BARS CAN BE CUT SHORTER TO KEEP THE BIKE RACK LOW ON YOUR DRAWBAR.

THIS DIAGRAM HIGHLIGHTS ALL DIMENSIONS WHEN THE 2 BIKE CARAVAN RACK IS TILTED. WE HAVE USED BOTH THE OFFSET TILT AND STANDARD TILT BRACKET TO PROVIDE THESE DIMENSIONS.

NOTE: YOU CAN MOUNT THE OFFSET BRACKET FACING TOWARDS THE CARAVAN, OR TOWARDS THE CAR.

NOTE: YOU WILL AUTOMATICALLY GET BOTH THE OFFSET AND THE TILT BRACKETS AS PART OF THE KIT.

THIS HANDY GUIDE WILL SHOW YOU THE DIMENSIONS FOR OUR CAR MOUNT KIT. IF YOU REQUIRE AN EXTRA LONG INSERT BAR TO CLEAR YOUR CARS REAR MOUNTED TYRE OR SIMILAR, YOU CAN PURCHASE FOR AN ADDITIONAL $70.
